HFE60_HONGFA Power Relay HONGFA SUBMINIATURE INTERMEDIATE POWER RELAY

Overvews:

HONGFA SUBMINIATURE INTERMEDIATE POWER RELAY
Relay Type: HFE60

· Low height 10.5mm
· Low coil power
· High switching capacity
1A: 8A 250VAC
2A, 1A+1B: 5A 250VAC
· 1 Form A, 2 Form A, 1 Form A+1 Form B configuration
· 3kV dielectric strength (between coil and contacts)
· Environmental friendly product (RoHS compliant)

SUBMINIATURE INTERMEDIATE POWER RELAY-HF46F

· 5A switching capability
· 10kV impulse withstand voltage
(between coil and contacts)
· Meets VDE 0700, 0631 reinforce insulation
· Highly efficient magnetic circuit for
high sensitivity: 200mW
· Extremely small footprint utilizing PCB area
· UL insulation system: Class F available
· Environmental friendly product (RoHS compliant)
· Outline Dimensions: (20.5 x 7.2 x 15.3) mm

Contact Data:

Contact Arrangement:1A

Contact Resistance:AgSnO2 , AgNi

Contact Rating:
3A 250VAC/30VDC
5A 250VAC/30VDC

Max. switching Voltage:277VAC/30VDC

Max. Switching Power:1385VA / 150W

Mechanical Endurance:5×106OPS

Electrical Endurance:1×105OPS

Characteristics:

Insulation Resistance:1000MΩ
Dielectric Strength:4000VAC
Operate Time (max):10ms
Release Time (max):10ms
Ambient Temperature:-40℃ ~ 85℃
Terminal Type:THT

Coil Data:

Nominal Voltage:(3~24)VDC
Coil Power: 0.2W

Cautions for usage of LD-P relays:

Max. applied voltage and temperature rise Proper usage requires that the rated voltage be impressed on the coil. Note, however, that if a voltage greater than or equal to the maximum applied voltage is impressed on the coil, the coil may burn or its layers short due to the temperature rise. Furthermore, do not exceed the usable ambient temperature range listed in the catalog
