    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors

    Ask Lasest Price
    Brand Name : ERNI
    Model Number : 354111
    Certification : RoHS
    Price : Negotiated
    Payment Terms : T/T, Western Union, MoneyGram
    Supply Ability : 5000pcs
    Delivery Time : 3-14days
    • Product Details
    • Company Profile

    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors

    354111 DIN Female Connector backplane Type M 2.54MM high power PCB Connectors

    Details :
    When small scale devices and operations need to interface with each other, use this 354111 backplane connector from ERNI Electronics.

    This F connector has 64 F contacts. It has a female type gender. It has a straight body orientation.

    Its pitch is 2.54 mm. This is a 3-row connector. It uses the solder termination method.

    354111 is housed in polybutylene terephthalate. This product is 95 mm long, 12.6 mm tall and 10.6 mm deep.


    Technical Data

    ApplicationsPCB Connectors, High Power,
    Pitch2.54 mm
    OrientationVertical
    GenderFemale
    No. of Pins60
    TerminationSolder
    Termination Length4 mm
    Max Operating Temperature125 °C
    Data Rate1 Gbit/s
    Mating Cycles400
    StandardIEC 60603-2
    ConfigurationType

    Environmental & Export Classifications

    ATTRIBUTEDESCRIPTION
    RoHS StatusRoHS Compliant
    Moisture Sensitivity Level (MSL)1 (Unlimited)
    ECCNEAR99
    HTSUS8536.69.4040


    Images :

    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors

    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors

    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors

    Ordering information for ERNI DIN41612/IEC60603-2 Connectors:

    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors

    354111 DIN Female Connector Backplane Type M 2.54MM High Power PCB Connectors
